2.4G Wireless Wifi Telemetry Module With Antenna For Pixhawk APM Mini APM Flight Controller It support Mobile Computer & can replace the 3DR data transmission module & free you from the limitation of USB (Universal Serial Bus) cable. It is suitable for all flight control with TTL interface. Description: Wireless Module:FCC compliant Wifi standard: 802.11 b/g/n Frequency Range: 2.4G-2.5G (2400M-2483M)
Size: 18.5 x 26mm Suitable For: Pixhawk, APM2.5/2.6, Mini APMTransmit power:- 802.11 b: +20d Bm- 802.11 g: +17d Bm- 802.11 n: +14d Bm Receive power:- 802.11 b: -91d Bm (11 Mbps)- 802.11 g: -75d Bm (54 Mbps)- 802.11 n: -72d Bm (MCS7) Connect data:- SSID: APMWIFI- Code: 12345678- Ground stataion IP: 192.168.4.2- Protocol: UDP- Braud: 57600 Usage:1. Directly insert in the flight contorls data transimission port. When powered, there will be a wifi named APMWIFI, the password is 12345678. If connect successfully, it will distribute you an IP address 192.168.4.2.2. Turn on ground station software, set connect as UDP protocol, 57600 braud, 14500 connect port. Noting:1. Operating voltage: 4V to 7V, maximum support to 12V, but this time it would be more serious fever.2. Working current: average current 0.11A, around the peak 0.2A, if connected to the flight control of other external devices more (such as GPS, OSD, head, etc.), the best flight control through the power management module powered by electricity supplyif transfer for APM flight control, the total current only to about 0.5A. Package Included:1 x 2.4G Wifi Telemetr
...

2.4G Wireless Wifi to Uart Telemetry Module With Antenna for Mini APM Flight Controller Use: Directly insert into the flight contorls data transimission gate. When powered, there will be a wifi called iffrc_wifi, the password is 1234567 8. If connect successfully, please visit 192.168.4.1 via your phone or PC to the settings page. Package included:- 1* Wifi data transmission module- 1* Pixhawk plug- 1* APM plug ...

2.4G+5G Wi Fi IP Camera Outdoor Wireless Surveillance Security Video Cam Night Vision Motion Detection Alarm APP Push Notifications Two-way Audio CCTV Camera ...

Only US$21.99, buy best 2.4g+bluetooth dual mode 8 colors backlight english air mouse touchpad for android tv box pc m 9 mini wireless keyboard sale online store at wholesale price. ...

2.4G/5.8G 2.15d Bi High Gain Dual-frequency External Antenna IPEX for FPV RC Drone Description: Item name: 2.4G/5.8G Dual-frequency external antenna Electrical Specifications Frequency range: 2400-2500 M Hz/5150-5350 M Hz Gain (d Bi): 2VSWR: 2.0 Input impedance (): 50 Iput connector type: I-PEXMaterial of Coaxxial Cable: 1.13 Mechanical Specifications Dimensions (mm): 100*9 Length of Coaxxial cable (mm): 200 Openrating temperature (℃): 45-85 Radone
Colour: Black
Features:* Exquisite appearance* Full day working* Optimized dimension* High gain, low standing wave, strong anti-interference ability Package Included:1x 2.4G/5.8G Dual-frequency external antenna

...

Description: Item Name: PCB Antenna
Material: FR-4 environmentally friendly materials Frequency Range:400 MHz ~ 2500 MHz
...

Specification: Standing wave ratio: S.W.R = 1.5 @ 2400 MHz ~ 2500 MHz / 5150~5850 M Hz Gain definition: 3d Bi 0.5 (* Typical* ) Band range: 2400 MHz ~ 2500 MHz 5150~5850 M Hz Impedance definition: 50 ohm Connector type: ring strip welding Cable length: 13CMPackage included:1 x 2.4G/5G/5.8G 3d Bi Dual Band WIFI Omnidirectional FPV Antenna Module Inner Aerial FPC ...

Description: Product name: ZP1001-04 Product

Size: 47.4 * 20.2 * 23.5CMCarton

Size:



...

2.4 Ghz 3d Bi Mini Antenna Linear Omni-directional Wi Fi bluetooth FPV Antenna Specification Frequency: 2400-2500 MHz S.W.R.: = 2.0 ; Return Loss -10DBAntenna Gain: 30.3d Bi Polarization: Linear Impedance: 50 Ohm Material Mechanical Characteristics Material of Radiator: Cu Cable Type: OD 1.13mm Operation Temperature :
- 10 C ~ + 180 CStorage Temperature :
- 10 C ~ + 180 CConnector: IPEXCable: RF113 Package Included 1 x Mini Antenna

...

Specification: Frequency 2400 ~ 2500 MHz S.W.R. = 2.0 Antenna Gain 3.00.7d Bi Polarization Linear Impedance 50 Ohm Material of Radiator PCBCable Type O.D. 178 mm Connector Type MCXPull Test = 1.0 kg Operation Temperature
- 40 C ~ + 65 CStorage Temperature
- 40 C ~ + 80 CPackage included:1 x 2.4 G Hz 3d Bi Omnidirectional High Gain Coaxial MMCX FPV Antenna for RC Drone

...
