Reptile CLOUD-149 3 Inch Frame + MAMBA F405 Mini MK2 25A ESC + GEPRC SPEEDX GR1408 3500KV Motor + GEMFAN 75mm 3.4 Inch Propeller Cinewhoop Combo Specification: Reptile CLOUD-149 3 Inch Frame Item name: CLOUD-149 Frame Kit Wheelbase: 149mm Structure: X-type Division Top plate: 2mm Side plate: 1.5mm Bottom plate: 3mm Internal

Height: 30mm Plastic parts: ABS material plastic Diversion ring Printed parts: TPU antenna base *1 Weight: 88GMAMBA F405 Mini MK2 25A ESCMamba F405 Mini FCItem name: F405 mini Betaflight Flight Controller Input: 3~4S LIPO (11.1V~14.8V)BEC: 5V 1AMCU: STM32F405 Gyro: MPU6000FLASH: 16MOSD: AT7456 Mounting: 20mm/M2 Weight: 3.5g Mamba F25 ESCItem name: Mamba F25HV ESCInput: 3~4S LIPO (11.1V~14.8V) Continue current: 20A4 Burst current: 25A (5S)CURR: 135A BEC: NO
Size: 30305mm Mounting: 20mm / M2 Weight: 8g GEPRC SPEEDX GR1408 3500KV Motor KV: 3500kv Thread: CW Thread Configu-ration: 9N12 P Stator Diameter: 14mm Shaft Diameter: 2mm Motor Dimension: 18.2x 31.5mm Weight: 15.2g (Not including wire) No.of Cells: 2-4 S Max Continous Power (W)180S: 222.3 Internal Resistance: 98m Max Current (180S): 22.3 A Max Effciency Current: (3.3-14.57A) 81%GEMFAN 75mm 3.4 Inch Propeller Brand: Gemfan Type: 75mm Ducted propeller Blades:3-Blade Pitch: 3.4in Material: pc Weight / g: 1.9g Center Hole Inner diameter: 5mm Prop Disk Diameter: 75mm Center Thickness: 7mm Max Prop Width:


...

Specification: Brand Name: Reptile Model:CLOUD-149 HDItem Name:149mm F4 3 Inch FPV Racing Drone Version: PNP (without Receiver)

...

Specification:  Brand Name: Reptile  Model:CLOUD-149  Item Name: Upper Plate / Bottom Plate Integrated Replace Frame Arm  Version: Upper Plate / Bottom Plate (Optional)  Application: Original replace part for Reptile CLOUD-149 FPV Racing Drone   Package Included: 1x Upper Plate OR 1x Bottom Plate ...

Reptile CLOUD-149HD 149mm Wheelbase 3 Inch Racing Frame Kit Compatible DJI Digital FPV System Specification: Brand Name: Reptile Model:CLOUD-149HDWheelbase: 149mm Upper plate length:156mm Lower plate length:156mm Weight: 115g (Include print part) Bottom plate: 2mm Top plate: 2mm Arm plate:3mm Position of FC installation hole: 20*20mm/30.5*30.5mm Camera mounting hole distance:20mm Distance of installation hole of motor:12mm Plastic parts: ABS material plastic Diversion ring Printed parts: TPU antenna base
Features:1. Suitable for DJI FPV System 2. Video unocclusion 3. Beautifully designed, rugged & durable 4. High quality carbon plate, precision cutting 5.

Includes:: 3D printed Parts for installing DJI FPV System Recommend Parts: Flight Controller: 20x 20mm OR 30.5x 30.5mm RF / Kiss / F4 / F3 / F7 FCBrushless ESC: 20A-50 A Propeller: 3 Inch Propeller Brushless Motor: 1306 / 1408 / 1506 Motor VTXFPV Camera: DJI FPV Air Unit Battery: 4S 650m Ah
- 6S 1300m Ah Lipo The following parts are compatible: (NOT Included)FCESC Stack: 20x 20mmi Flight Succe X-D Mini F7 Twin G Stack (F7+40A ESC) Brushless Motor:MAMBA 1408 4000KV 4S Brushless Motor Propeller:2 Pairs i Flight Mega Bee V2 Parts 3045 3x 4.5 3 Inch 3-Blade Propeller VTXCamera:DJI Digital FPV System Air Unit HD Camera Goggle Radio Transmitter Combo Lipo Battery: Tattu R-Line V1.0 14.8V 850m Ah 95C 4S1P Lipo Battery XT30 Plug Package Included:1x Top plate 2x Side plate 1x Bottom plate 2x Arm plate 4x plastic Divers



...

REPTILE DRAGON-1200 1200mm Wingspan EPP Twin Motor Multirole Aerial Survey FPV RC Airplane KIT/PNPDescription Model: DRAGON-1200

...

REPTILE FALCON-220 220mm FPV Racing Drone PNP OMNIBUS F4 V3 30A BLHELI_S 5.8G 48CH VTXSpecifications: Brand Name: REPTILEItem Name: FALCON-220 FPV Racing Drone Wheelbase: 220mm Firmware: Betaflight_3.2.5_OMNIBUSF4SDInput Voltage: Support 3-4S Lipo Motor: 2205 2300kv Propeller: 5046*3 (4pairs) Weight: 270 grams without battery or props Frame: FALCON-220 Carbon: Full 3K carbon fiber Twill CNC: High precision CNCWheelbase: 220mm Thickness of bottom plate: 3mm Thickness of top plate: 2mm Thickness of lens plate: 2mm Thickness of arms plate: 5mm Flight Controller:OMNIBUS F4 V3MCU: STM32F405MPU: MPU6000ESC: 30A * 4 BLHeli_s (Dshot 150/300/600) support 3~4S Li Po VTX: 5.8 G Hz (48 Channel) (OFF/25/200/600m W) Package Included:1 x FALCON-220 Farme KIT4 x 5046-3 Propeller 1 x Battery strap 1 x Omnibus F4 V3 Flight Controller 1 x 4 in 1 BLHELI_S 30A ESC4 x 2205 2300KV Motor 1 x 5.8 G Hz VTX (48 Channel) (OFF/25/200/600m W)1 x FPV Camera 1000 TVL 2.1mm LENS4 x 5046 propeller ...

Reptile Flight Controller For Swallow-670 S670 S800 Grey RC Airplane PNP Version Description: Brand Name: Reptile Item Name: Flight Controller Type: SMDDimension: 52x 40x 4mm Input Voltage: 3S-6S (7-28V) Output Voltage: 5V/9 V Output Current Peak: 3ADCDC Conversion Efficiency: 92% Full Load Output Ripple Vpp: 50m V Output Accuracy:0.1 V No-load Current IQ: 0.5m A Cooling Method: Natural cooling Operating Temperature: -40 ℃ ~ +85 ℃ Storage Temperature: -40 ℃ ~ +125 ℃ Relative Humidity: 20-90%PCB Layers: Double panel Flight control Voltage: 5-6 V Supported Aircraft Type: Normal / V-Tail / Delta Wing (Switches via Jog Jumper Weld) Mode of work: ordinary stability / lock mode / off Application: Suitable for Reptile S670 & S800 Grey version RC Airplane, NOT suitable for S800 Black version. If you want to order S800 Black version Flight Controller, please Click Here Package Included:1x Reptile Flight Controller ...

Description: Brand Name: Reptile Item Name: Harrier-S1100
Colour: Black
Material: EPP Foam Wingspan: 1100mm

...

Description: Brand Name: Reptile Item Name: Harrier-S1100
Colour: Black
Material: EPP Foam Wingspan: 1100mm

...

Description: Brand Name: Reptile Item Name: Harrier-S1100 Fuselage Hatch Cover
Colour: Black
Material: EPP Foam

...
