SKYSTARS 2019 Ghostrider X95 95mm FPV Racing RC Drone DIY PNP BNF w/ F4 OSD 200m W VTX 20A BLHeli_S ESC 700TVL Camera Item Specification Ghostrider X95 Frame Kit Wheelbase: 95mm
Colour: translucence
Material: elastic plastic Screws: 10.9 class screw Weight: 25g SKYSTARS ST1104 7500KV Brushless Motor KV: 7500KVLipo cell: 2S20A 2-4S BLHeli_S 4 in 1 ESCInput voltage: 2-3S lipo battery Constant current: 20 A Peak current: 25ABEC ouput: NOFirmware: BLHeli_S
Size: 27x 27mm (main board) 27x 31mm (including pad) Installing holes distance: 20x 20mm, M2 Weight: 4g MOS tube: finest top quality MOSFETSupport Damped Mode, Oneshot 125, Oneshot 42, Multishot, Dshot 150/300/600, forward & reverse.F4 Flight Controller (DShot Version)MPU: MPU6000-SPICPU: STM32F405RGT6, dual 8K. Built-in betaflight OSD to adjust PIDBEC output: 5V@2 A Board

Size: 25x 25mm Installing holes distance: 20x 20mm Mounting holes: M2 Weight: 2.3g Support SUBS/PPM/DSMX receiver 40CH 25m W/100m W/200m W switchable FPV VTXOutput power: 25m W/100m W/200m W switchable Control mode: button OR channel changes Battery: 7-26V, BEC 5V-1A190m A----200m W Video system: NTSC/PALFrequency: 5.8 G Hz 5 bands 40channels, with Raceband: 5645-5945 MHZ
Size: 24*24mm (L*W), installing holes distance: 20*20mm Weight: 2.5g 700TVL CMOS camera Image sensor: 1/3 CMOS sensor Horizontal resolution: 700TVLLens: 2.3mm Lens FOV: 115 degree (2.3mm) Signal system: PAL/NTSCS/N ratio: 50d B (AGC OFF) Min.illumination: 0.1 Lux/1.2 F Day/ Night: Auto Power: DC 5 V Net weight: 3g Dimensions: 19mm*14mm*13mm Lipo battery Not includ





...

SKYSTARS 2019 Ghostrider X95 95mm FPV Racing RC Drone Spare Part 700TVL CMOS Camera 2.3mm Lens Description: Brand name: SKYSTARSItem name: 700TVL CMOS Camera Image sensor: 1/3 CMOS sensor Horizontal resolution: 700TVLLens: 2.3mm Lens FOV: 115 degree (2.3mm) Signal system: PAL/NTSCS/N ratio: 50d B (AGC OFF) Min.illumination: 0.1 Lux/1.2 F Day/ Night: Auto Power: DC 5 V Net weight: 3g Dimensions: 19mm*14mm*13mm Package included:1 x 700TVL CMOS camera 1 x wire ...

Skystars 300m Ah 7.4V 80C 2S Lipo battery XT30 Plug for Whoop Mobula 7 Beta 75x Tiny Frog 75x RC Drone Specification: Brand name: Skystars Item name: lipo battery Rated Capacity: 300m Ah Rated voltage: 7.6v Weight: 18.28g Discharge rate: 80c
Size: 16.5*13*47mm Suitable for: 2S Whoop Mobula 7, Beta 75x, Tiny Frog 75x, Rex 80. Package Included:1PC x 2s 300m Ah 7.4V lipo battery
...

SKYSTARS 35A Blheli_32 bit 2-5S Dshot 1200 Built-in LED Brushless ESC for RC Drone FPV Racing Specification: Brand name: SKYSTARSItem name: 35 A Blheli_32 bit ESCMCU: STM32F051 Firmware: BLHeli_32 Input voltage: 2-5 S Continuous current: 35 A Burst current:45A =10 S Product weight: 5.7g
Size: 23x 14x 5 mm BEC: NOBuilt-in switchable RGB LEDFunctions: DShot 150, DShot 300, DShot 600, Multishot, Oneshot 125, Oneshot 42 Mosfet: TOSHIBA N channel, independent half-bridge driver chip PCB: 3OZ copper thickness, gold plated

Features:- Support Dshot 1200 in default out from factory- Also support Oneshot 42, Oneshot 125, Multishot, Dshot 150, Dshot 300 & Dshot 600- Ultra light & ultra small ESC- The color of RGB LED can be set by Blhelisuite.- Powered by high performance STM32 MCU frequency up t 0 48 MHZ- Composed of 3 Oz gold plated PCB- Flashed with the latest BLheli 32 firmware- Supports higher KV motor & more power load, more suitable for violent flight of racing drone.- Aluminum heat sink effectively slow down the temperature rise. Package included:1x SKYSTARS35 A Blheli_32 bit ESC


...

Skystars Super Light 3g 1103 11000KV 1.5mm Shaft 2-3S Brushless Motor for RC Drone Specification: Brand Name: Skystars Item Name:1103 11000KV2-3S Brushless Motor KV: 11000KVInput Voltage: 2-3S Lipo Version: One PC / 4 PCS (Optional) Shaft Diameter: 1.5mm Motor

Height: 15.6mm Plug Connector: Micro JST-1.25 3 Pins Cable Length: 48mm Weight: 3g (without cable) Recomend Propeller: Gemfan 40mm 1.5mm Hole 4-Blade Propeller Recommend FCESC: Crazyfrog 2S-3S Whoop FC15A BL_S 4in 1 ESCApplication: compatible with Beta 75X, Tiny Frog 75X, REX80 & Mobula 7 etc. whoop fpv drone Package Included: One PC Version:1x Skystars 1103 11000KV Motor 1x bag of Screws 4 PCS Version:4x Skystars 1103 11000KV Motor 4x bag of Screws

...

PRODUCT DESCRIPTIONAngela 145 frame is wished to be designed to carry a Go Pro 5/6/7! This is the Angela 145, 3inch (FPV Whoop Drone), Small space design, Tight gaps, Indoor safety, Thats what you want 4K, here you are. lets go fly. The machine use 3k ultra-light carbon plate. the whole weight of Angela 145 is only 249g. (with ratel cam version ) To strengthen the four arm With strength brace bar. Indoor fly, carrry Gopro, safety & reliability. Angela 145 uses YFS screws so that it is not easy to be rusted & the strength (grade 12.9) can meet the needs. By now, we have spent almost three month testing Angela 145, definitely, it is a good choice for get footage in 4K.

Features:-light weight fuselage with prop protective ring is safer for indoor shooting-A variety of shooting equipment selection, Go Pro 7+FPV cam-Bottom plate: With strength brace bar Specification:-Brand name: SKYSTARS-Item name: Angela 145-Wheel base: 145mm-Bottom plate thickness: 3mm-Top plate thickness: 2mm-Top & bottom plate spacing: 30mm (aluminum column height 30mm)-FC pattern: 20*20mm-FPV CAM spacing: 19mm-Propeller: Gemfan 3inch-Screws: YFS 12.9 class screw-skystars Talon X mini F4 Towers 20*20-F4 flight controller: STM32F405 Six-Axis; 5V 2A BEC;-Camera: Caddx Ratel 2.1mm Camera-VTX: Skystars 25-500MW 7V~24V Version-ESC: SKYSTARS 35A Blheli S ESC-Motor: Skystarts S1408 3800KV-Weight:249g Recommend battery: 3-4S 1500-1800m AHPlease note: The PNP (Plug & Play) version comes without battery, charger, Gopro, receiver or r

...

Skystars Angela V2 168mm 3 Inch Cinewhoop Frame Kit with Duct 20x 20mm Mounting Hole for RC Drone FPV Racing  There are red & yellow color options for this frame kit.   The color means the duct & other printed parts color.   Specification:-Brand name: SKYSTARS-Item name: Angela 1V2-3inch-Wheelbase:168mm-Bottom plate thickness: 2mm-Top plate thickness: 2mm-Top & bottom plate spacing: 25mm (aluminum column height 25mm)-FC pattern: 20*20mm-FPV CAM spacing: 19mm-Propeller: Gemfan 3inch-Screws: YFS 12.9 class screw-Weight:188g 

Features:-light weight fuselage with prop protective ring is safer for indoor shooting-A variety of shooting equipment selection， Go Pro 7+FPV cam or Runcam hybrid 4K.-Bottom plate: With strength brace bar   Note: Camera mount for Gopro is not Included. Package Included:1 x Angela V2 Frame Kit (Include TPU parts)

...

Skystars Angela V2 168mm 3 Inch HD Cinewhoop Frame Kit w/ Duct compatible DJI FPV Air Unit Specification:-Brand name: SKYSTARS-Item name: Angela 1 V2 3 Inch HD-Wheelbase: 168mm-Bottom plate thickness: 2mm-Top plate thickness: 2mm-Top & bottom plate spacing: 25mm (aluminum column height 25mm)-FC pattern: 20*20mm-FPV CAM spacing: 19mm-Propeller: Gemfan 3 Inch-Screws: YFS 12.9 class screw-Weight: 188g  

Features:-light weight fuselage with prop protective ring is safer for indoor shooting-A variety of shooting equipment selection， Go Pro 7+FPV cam or Runcam hybrid 4K.-Bottom plate: With strength brace bar  Note: Camera mount for Gopro is not included. Package Included:1 x Angela V2HDFrame Kit (include TPU parts)

...

Skystars Angela 145 4K 145mm F4 OSD 3-4S 3 Inch Whoop FPV Racing Drone PNP BNF w/ Runcam Hybrid 4K Camera Specification: Brand Name: Skystars Model: Angela 145 4 K Item Name:145mm F4 OSD 3-4S 3 Inch Whoop FPV Racing Drone Receiver: Without Receiver/ Frsky XM+ RX/ Frsky R-XSR RX/ Frsky R9MM RX (Optional) Weight: 258g Angela 145 145mm Frame Kit Brand Name: Skystars Model: Angela 145 Wheelbase: 145mm
Material: 3K Carbon fiber Arm Plate Thickness: 3mm Thickness of top plate: 2mm Thickness of bottom plate: 3mm Screws: YFS 12.9 class screw Weight: 128g F4 Flight Control Board (D-Shot Version)MPU: 6000CPU: STM32F405RGT6 Input Voltage: 2-4S Lipo Built-in Betaflight OSD to adjust PIDBEC Output: 5V@2A
Size: 20x 20mm board, 2mm mounting holes (M3) Weight:4g Support Subs/PPM/DSMX receiver 35A 2-4S Blheli_S 4in 1 ESCInput Voltage: 2-4S Lipo Constant Current: 35 A Burst Current: 38ABEC Ouput: NOFirmware: BLhelis
Size: 27x 27mm (main board) 27x 31mm (including pad) Installing Hole: 20x 20mm, M2 Weight: 4g MOS Tube: finest top quality MOSFETSupport Damped Mode, Oneshot 125, Oneshot 42, Multishot, Dshot 150/300/600, forward & reverse 1408 3800KV Motor Brand Name: Skystars Item Name:1408 3800KV Racing Edtion Motor Gemfan 3 Inch Propeller Brand Name: Gemfan Item Name: 3 Inch 3-Blade Propeller
Colour: Black Quantity: 4 CW4 CCW5.8G 48CH 25/200/500m W VTXOutput power: 25m W/200m W/500m W switchable Control mode:button OR Channel changes & Pitmode setting BAT: 7-26V, BEC 5V-1A145m A----500m W Video system: NTSC/PALAntenna: IPEXFrequency: 5.8 G Hz 5 bands 48channel



...

Skystars Angela 145 Spare Part 145mm Wheelbase 3mm Arm 3 Inch Frame Kit for RC Drone Specification: Brand Name: Skystars Model: Angela 145 Item Name:145mm Wheelbase 3mm Arm 3 Inch Racing Frame Kit Wheelbase: 145mm
Material: 3K Carbon fiber Arm Plate Thickness: 3mm Thickness of top plate: 2mm Thickness of bottom plate: 3mm Screws: YFS 12.9 class screw Weight: 128g Application: Original Replace Empty Frame for Skystars Angela 145 Racing Drone Click here to buy complete Angela 145 FPV Drone. Recommend Parts: Flight Controller: 20x 20mm F3/ F4 Flight Controller Brushless ESC: 20x 20mm 20-35A ESCBrushless Motor: 1408 / 1306/ 1506 Motor Propeller: 3 Inch Propeller Lipo Battery:3-4S 1500-1800m Ah Lipo The Following Parts are Compatible: (NOT Included)FCESC Stack: HGLRC XJB F438 Stack F4 FC33A BL_S ESCBrushless Motor:i Flight XING 1408 3600KV 4100KV 2-4S Brushless Motor Propeller:2 Pairs Gemfan Flash 3052 3-blade Propeller 5mm Mounting Hole Package Included:1x Skystars Angela 145 Frame Kit 1x 3D TPU Mount 1x Battery Strap
...
