SPEDIX ES25 25A 2-4S Blheli_S FPV Racing Brushless ESC for RC Drone Spedix ES25 speed controller is designed for 150-280 size racing multirotors. The product is powered by high performance EFM8BB21 MCU, & flashed with the latest BLHeli_S program. With the combination of dedicated drive chip, this speed controller has excellent response speed & efficiency. The filter circuit of ES25 is composed of 12 low ESR capacitors, a number much more than competitors that use only 4-5 of them. As a result, ES25 has less current ripples & higher system stability, & less interference to wireless video transmitters. In additional to excellent design, ES25 is also made from finest top quality electronic parts. It is composed of 3 Oz gold plated PDB, & genuine components from estimated suppliers such as STMicroelectronics of Switzerl&, & AVX of USA. Excellent design, authentic electronic components, & good manufacturer process all together make the ESC an excellent product with great quality, reliability, & stability. Furthermore, the size of the product is managed to be as small as most compact products in the market. Specification: Brand name:SPEDIXItem name:ES25 25A Brushless ESCContinuous Current: 25 A Burst Current: 35 A Voltage Range: 2-4S Li Po Firmware: BLHe Li_SDimensions: 12.8X25.8X5 mm Weight: 5.9g Package Included:1x ES25 BLHe Li_S 25A ESC ...

SPEDIX ES30 HV 30A 3-6S Blheli_S FPV Racing Brushless ESC for RC Drone Specification: Brand name:SPEDIXItem name: ES30 30A Brushless ESCContinuous Current: 30 A Burst Current: 40 A Input Voltage: 3S-6S LiPodimensions: 14.8x 29x 5mm Weight: 7.9g Feature: Ultra-light & ultra-small ESC beyond imagination Powered by high performance EFM8BB21 MCUFlashed with the latest BLHeli_S program With the combination of dedicated drive chip Composed of 3 Oz gold plated PCBSupport Dshot Package Included:1x Spedix ES30A HV ESC ...

Spedix GS 35A 4 IN 1 ESC BLHeli_32 Dshot 1200 2-4S For RC Drone FPV Racing Multi Rotor Description: Brand name: Spedix Item name: GS 35A 4 In 1 ESCFirmware: BLHeli_32bit Input: 2-4 cell lipo Cont./ Burst current: 30A/40A=10S
Size: 37x 41x 5mm Weight: 11.8g (not including cables) Current detection supported To install the software of BLHeli_32 Android APPplease Click Here. Package included:1 x GS 35A 4 In 1 ESC
...

Spedix GS30 30A Bl Heli 32 Bit ESC 2-4S Support Dshot 1200 for FPV Racing Specification: Item name:GS30 ESCSt&-sized MOSFET (5x 6) Firmware: BLHELI_32 bitinput: 2-4 S Cont Current: 30 A Burst current: 40A10s
Size: 23x 14x 5mm Weight: 6g (include cables) To download the installation package of BLHeli_32 Android APP pleaseclick here.

Features:-Ultra-light & ultra-small ESC beyond imagination-Powered by high performance STM32F051 MCU-Flashed with the latest BLHeli 32 firmware-With the combination of dedicated drive chip-Composed of 3 Oz gold plated PCB-Support Dshot 1200 Package included:1*GS30 ESC


...

Spedix GS35A BLHeli_32 2-6S DSHOT FPV Racing Brushless ESCSpecification: Brand name: Spedix Item name: GS35A ESCFirmware: BLHELI 32 BITInput: 2-6S Cell Lipo Cont./ Burest Current: 35A/45A 10S
Size: 28.5x 16x 5.5mm Weight: 8.3g (including cables) Telemetry port & current protection supported To download the installation package of BLHELI_32 Android APP please Click Here. Package included:1 X GS35A BLHeli_32 ESC
...

Spedix GS40F4-In-1 Mini 3-6S40AESCGS40F4IN1MINIisanextremelyreliable 20x 20mmmount 6S4IN1ESC. Limitedbythesmallersizeof 20x 20mm ESC, engineershavealwaysused 3mmmini MOSFETs, whicharenotreliablefor 6S. Thiscompromisemadethese ESCsvulnerabletodamageduetohighheatandcurrent/ Voltagedemandsofthe FPVmarket. Withtheinnovativedesignofthis 4-in-1ESC, byseparatingthecontrolboardandthepowerboard, Spedixsuccessfullyimplementedfull-size 5x 6mm MOSFETsontothis 20x 20mmspeedcontroller. Theyareabletopresentyouwithahigh-performancemini 6 Scapable 20x 20mm ESCofextremereliabilityandresponsiveness. Bycombiningreliablehardwarewiththefastest GD32F3MCUinthemarket, Spedixisabletopresentahigh-performancemini 20x 20mm ESCofextremereliabilityandresponsiveness. Perfectasacombowiththe Brain FPVRadix L Ioranyother 20x 20orfull-sizedflightcontroller.
Features: Innovativedouble-deckdesignenablestheimplementationoffull-size 5x 6MOSFETon 20x 20mmmini 4IN1ESC.40VMOSFETimprovestheoverallreliabilityinfastresponsetothrottlesignals, makingthe 6cellinputcapableintherealworld GD32F3MCUprovideshighestresponsivenessinthemarket. Extremelysmallsizemakesmountingonsmallerframeseasierthanever. Specifications: Specifications: Input:3-6 Cell Li Po Continuous Current:40 A Burst Current:50A10SBEC: No Current Detection:YESFirmware:BLHeli_32 Dimensions:40x 31x 8mm Mount Holes:20x 20mm Weight:13.2g Application:200-300mmracingdrone Package Included:1x Spedix GS40F4-In-1 Mini 3-6S40AESC4x Grommets 4x Standoffs 1x Wireset 1x 470u F35 V Capacitor
...

Spedix GS45 45A BLheli_32 3-6S 4 in 1 DShot 1200 ESC w/ 10V BEC Output for RC Drone Specification: Brand Name: Spedix Model: GS45 Item Name:45A BLheli_32 3-6S 4in 1 Brushless ESCInput Voltage: 3-6S Lipo Con. CUrrent: 45 A Burst Current: 55A (10S)BEC:10V/2 A Current Detection: Yes Firmware: BLHeli_32 Dimensions: 40.5x 42x 6.5mm Mount holes: 30.5x 30.5mm Diameter of Mount holes: 3mm Weight: 17g Package Included:1x 45A 4in 1 ESC1x XT60 Connector Cable 2x Cable 1x Capacitor 5x Cable Tie ...

SPEDIX IS30 30A 2-4S Blheli_S DSHOT600 Ready FPV Racing Brushless ESC for RC Drone Specification: Brand name:SPEDIXItem name:IS30 30A ESCMax. continuous current: 30.0 A Dimensions (x, y, z in mm): 23x 14x 5 Continuous BEC Current: 0.0 A Max BEC Current: 0.0 A Jeti Box Compatible (JBC): No BEC Type: No BECDimensions: 2314x 5mm Weight: 9.0g (0.3oz.) Feature: Equipped with standard-sized MOSFET DFN5X6 (5x 6mm), better heat dissipation, lower resistance, & higher reliability. Small

Dimensions of 23x 14x 5mm, the same size as other ESCs of 3x 3mm MOSFETS. Fast EFM8BB21 MCU, independent half bridge drive chip, & 3 Oz copper PCB with high TGSupport Dshot Package Included:1 x IS30 30A ESC

...

Specification: Brand name: Spedix Item name:IS35 35A ESCInput Voltage: 2-5 S Max. Continuous Current: 35 A Max Burst Current: 45A (10 sec.) Firmware: Blheli_SBEC: No Current Detection: Yes Dimensions:29x 32x 6.5mm Stack

Size: 20x 20mm, M3 Weight: 7 G Features High reliability. This design allows low pro file stack & prevent interferences between wires, ESC, & flight controller. The potential interference between standoffs & electronic parts were also taken into consideration in the design. Fragile parts are now away from the mounting holes. The silicone rings provided will prevent the standoffs to short the PCB & electronics parts during a crash. The small size & square shape of the ESC board is compatible with most frames available in the market. The product comes with 2 different cables & spare connector housings to accomodate the multipin connectors used on different flight controllers. Package Included:1 x IS35 35A Blheli_S 2-5S 4 IN 1 Brushless ESC

...

SPEDIX LS40 Slim 40A 3-6S Blheli_32 M4-32bit F4 Core Brushless ESC for RC Drone FPV Racing Specification: Brand name:SPEDIXItem name:LS40 Slim 40A Brushless ESCInput Voltage: 3-6 S Max. Continuous Current: 40 A Burst Current (10 Sec.): 50ABEC: No Current Detection: No Firmware: BLHeli_32 Integrated RGB LEDDimensions: 9x 38x 6mm Weight: 7.5g Feature: Equipped with the latest STM32L4 chip (F4 Core) & BLHeli_32 firmware, LS40A has the fastest response speed compare to any other similar products in the market. Ultra-slim design. LS40A fits narrower arms of modern racing drones guaranteeing a clean build. Powered by full-size 40V MOSFET to ensure extreme reliability. Customized aluminum heat sinkfor enhanced cooling & impact resistance. Intergrated RGB LED support multiple color settings. Package Included:1 x LS40 Slim 40A Brushless ESC1 x Heat Shrink ...
