LDARC / Kingkong 20x 20mm Flytower 12A BLheli_S 2-3S ESCOmnibus F4 FC AIO OSD48CH 0/25/100/200m W VTXNotice: The ESC is upgraded in 2-4S Lipo support. Will update photos asap. Specification: Brand Name: LDARCItem Name: 12A BL_s 4 In 1 ESCF4 FC Integrated with OSD40CH 0/25/100/200m W VTX Flytower Flytower
Height: 21mm 12A 4 In 1 ESC (Bottom Level) Con. Current: 12 A Peak Current: 15A (5s) Firmware: BLHeli_SInput Voltage: 2-3S
Size: 25x 28mm Mounting Hole: 20x 20mm Net Weight: 4g Support Oneshot, Multishot, DShot 150/300 & DShot 600 Omnibus F4 Flight Controller (Middle Level) Firmware: Omnibus F4 SD- Built-in Betaflight OSDOutput Voltage for Camera: 5V
Size: 25x 25mm Mounting Hole: 20x 20mm Weight: 3.7g Support DSMX, SBUS & PPM Receiver 5.8G 48CH 0/25/100/200m W VTX (Top Level) Channel: 25CHPower:0/25/100/200m W (Switchable) Output Voltage for Camera: 5V
Size: 25x 25mm Mounting Hole: 20x 20mm Weight: 2g Blue Light points at the CH indicator (CH1-CH8, flashes 1-8 times) Green Light points at the Band Indicator (Band A- Band F, flashes 1-6 times) Red Light points at the Power Indicator (25-100m W, flashed 1-3 times) Package Included:1x Omnibus F4 Flight Controller 1x 12A BL_S 4 In 1 ESC1x 48CH 25/100/200m W VTX1x bag of Screws & Standoffs 1x Antenna 3x Cable
