Holybro Kakute F7 V1.5 Flight Controller 65A BL_32 Tekko 32F3 Metal 4in 1 ESC 4-6S Stack Combo for RC Drone Specification: Brand Name: Holybro Item Name: F7 Flight Controller 65A 4 in 1 ESC Stack Kakute F7 V1.5 Flight Controller (Manual ) Brand name: Holybro Item name: Kakute F7 V1.5MCU: STM32F745 32-bit processor IMU: MPU6000 (SPI) Barometer: BMP280 Current Sensor: Approx. 130 amps maximum measurable value USB VCP Driver (all UARTs usable simultaneously; USB (Universal Serial Bus) does not take up a UART)6 hardware UARTS (UART1, 2, 3, 4, 6, 7) All UARTS support hardware inversion. SBUS, Smart Port, & other inverted protocols work on any UART without uninvert hack. Supports serial receivers (SBUS, i Bus, Spektrum, Crossfire) only. PPM & PWM receivers are not supported.TF card for Blackbox logging Dimensions: 35x 41x 7mm (
Includes: foam-mounted gyro board in height) Mounting Holes: Standard 30.5mm square to center of holes Weight: 8g Tekko 32F3 Metal 4in 1 ESC (Manual) Brand Name: Holybro Model: Tekko 32F3 Metal F3 (M4 Core) MCU, Runs BLHELI32 firmware, the MCU works at 108 Mhz The 4in 1 has onboard analog current sensor, & TLM function (then no current reading over TLM) Using metal case mosfet for better Heat dissipation Supports Lipo 4-6 S Ext. cap needed for 6s (470uf 35v for 6s usage.)
Size:42 x 42 mm Mounting holes:30.530.5mm Weight: 12g Notice: The air flow is very import if you want to run this 4in 1 in high current. The input cable (from lipo to 4in 1), should be good soldered, & at least 12AWG

Features:- The 4in 1 has onboard



...

Holybro Kakute F7 V1.5 Flight Controller Atlalt HV V2 40CH VTX65A BL_32 Tekko 32 F3 Metal 4in 1 ESC Combo Specification: Brand Name: Holybro Item Name: F7 FC65A 4in 1 ESC5.8G 40CH VTX Stack Combo Stack

Height: 26mm Kakute F7 V1.5 Flight Controller (Manual) Brand name: Holybro Item name: Kakute F7 V1.5MCU: STM32F745 32-bit processor IMU: MPU6000 (SPI) Barometer: BMP280 Current Sensor: Approx. 130 amps maximum measurable value USB VCP Driver (all UARTs usable simultaneously; USB (Universal Serial Bus) does not take up a UART)6 hardware UARTS (UART1, 2, 3, 4, 6, 7) All UARTS support hardware inversion. SBUS, Smart Port, & other inverted protocols work on any UART without uninvert hack. Supports serial receivers (SBUS, i Bus, Spektrum, Crossfire) only. PPM & PWM receivers are not supported.TF card for Blackbox logging Dimensions: 35x 41x 7mm (
Includes: foam-mounted gyro board in height) Mounting Holes: Standard 30.5mm square to center of holes Weight: 8g Tekko 32F3 Metal 4in 1 ESC (Manual) Brand Name: Holybro Model: Tekko 32F3 Metal F3 (M4 Core) MCU, Runs BLHELI32 firmware, the MCU works at 108 Mhz The 4in 1 has onboard analog current sensor, & TLM function (then no current reading over TLM) Using metal case mosfet for better Heat dissipation Supports Lipo 4-6 S Ext. cap needed for 6s (470uf 35v for 6s usage.)
Size:42 x 42 mm Mounting holes:30.530.5mm Weight: 12g Notice: The air flow is very import if you want to run this 4in 1 in high current. The input cable (from lipo to 4in 1), should be good soldered, & at least 12AWGAtlalt HV V2



...

Holybro Kakute F7 V1.5 Flight Controller Atlatl HV V2 VTX4 PCS 65A BL_32 Tekko 32 F3 Metal ESC Combo Specification: Brand Name: Holybro Tekko 32 F3 Metal ESCModel: Tekko 32 F3 Metal Item Name: 65A BL_32 DShot 1200 ESCQuantity: 4 PCSCon. Current: 65 A Peak Current: 80 A Input Voltage: 3-6S Lipo Support Ext. cap needed for 6s (220uf 35v for 6s usage.)- F3 (M4 Core) MCU, Runs BLHELI32 firmware, the MCU works at 108 Mhz- Mosfet tested at 4S 65A, under props, nothing covered for 1min- Onboard WS2812B LED
Size: 18 x 27 mm Weight: 4.4g/PCKakute F7 V1.5 AIO (Manual) Item Name: F7 Flight Controller AIO OSD BEC & Current Sensor MCU: STM32F745 32-bit processor IMU: MPU6000 (SPI) Barometer: BMP280 Current Sensor: Approx. 130 amps maximum measurable value USB VCP Driver (all UARTs usable simultaneously; USB (Universal Serial Bus) does not take up a UART)6 hardware UARTS (UART1, 2, 3, 4, 6, 7) All UARTS support hardware inversion. SBUS, Smart Port, & other inverted protocols work on any UART without uninvert hack. Supports serial receivers (SBUS, i Bus, Spektrum, Crossfire) only. PPM & PWM receivers are not supported.TF card for Blackbox logging Dimensions: 35x 48x 7mm (
Includes: foam-mounted gyro board in height) Mounting Holes: Standard 30.5mm square to center of holes Weight: 11.2g Atlatl HV V2: Item Name: 5.8G 40CH 25/200/500/800m W FPV Transmitter Model: Atlatl HV V2 Transmitting Output Power: 25m W/ 200m W/ 500m W/ 800m W Switchable Audio: 6 MHz + 6.5 MHz Mono Antenna Connector: MMCXInput Voltage: 7-28V (2-6S Lipo) Dimen

...

The Holybro Kakute F7 flight controller makes it easy to build your multirotor. It integrates flightcontroller (FC) & on-screen display (OSD) in one. The Kakute F7’s layout makes it easy towire up the other components of the multirotor while keeping the build neat & tidy.IMU upgraded to MPU6000, Re-designed & more reliable damping structure. Kakute F7 V1.5 Specifications:• MCU: STM32F745 32-bit processor• IMU: MPU6000 (SPI)• Barometer: BMP280• Current Sensor: Approx. 130 amps maximum measurable value• USB (Universal Serial Bus) VCP Driver (all UARTs usable simultaneously; USB (Universal Serial Bus) does not take up a UART)• 6 hardware UARTS (UART1, 2, 3, 4, 6, 7)• All UARTS support hardware inversion. SBUS, Smart Port, & other inverted protocols work onany UART without “uninvert hack”.• Supports serial receivers (SBUS, i Bus, Spektrum, Crossfire) only. PPM & PWM receivers are notsupported.• TF card for Blackbox logging• Dimensions: 35x 41x 7mm (
Includes: foam-mounted gyro board in height)• Mounting Holes: Standard 30.5mm square to center of holes• Weight: 8g
Features:• Supports Betaflight, Butterflight, & Cleanflight.• Betaflight OSD. Change PIDs, adjust common configuration parameters, & change videotransmitter channel & power level, all using your transmitter sticks & goggles.• Soft-mounting built in. The IMU (“gyro”) chip on this board is mounted on vibration-isolatingfoam. This means that there is no need to soft-mount the board itself.• High-performance / low-noise / high sensitivity IMU. MPU6000 with 6-ax

...

The Holybro Kakute F7flightcontrollermakesiteasytobuildyourmultirotor. Itintegratesflight controller (FC)andon-screendisplay (OSD)inone. The Kakute F7slayoutmakesiteasytowireuptheothercomponentsofthemultirotorwhilekeepingthebuildneatandtidy. IMUupgradedto MPU6000, Re-designedandmorereliabledampingstructure Specifications MCU:STM32F74532-bitprocessor IMU:MPU6000 (SPI) Barometer:BMP280 Current Sensor: Approximately 130ampsmaximummeasurablevalue USBVCPDriver (all UARTsusablesimultaneously;USBdoesnottakeupa UART)6hardware UARTS (UART1, 2, 3, 4, 6, 7) All UARTSsupporthardwareinversion.SBUS, Smart Port, andotherinvertedprotocolsworkonany UARTwithoutuninverthack. Supportsserialreceivers (SBUS, i Bus, Spektrum, Crossfire)only.PPMand PWMreceiversarenotsupported.TFcardfor Blackboxlogging Dimensions:35x 41x 7mm (
Includes:foam-mountedgyroboardinheight) Mounting Holes: Standard 30.5mmsquaretocenterofholes Weight:8g Features Supports Betaflight, Butterflight, and Cleanflight. Betaflight OSD. Change PIDs, adjustcommonconfigurationparameters, andchangevideotransmitterchannelandpowerlevel, allusingyourtransmittersticksandgoggles. Soft-mountingbuiltin. The IMU (gyro)chiponthisboardismountedonvibration-isolatingfoam. Thismeansthatthereisnoneedtosoft-mounttheboarditself. High-performance/low-noise/highsensitivity IMU.MPU6000with 6-axisgyroandaccelerometer. Readyforautonomousflight: Integrated BMP280barometerand SCL/SDApadsforusewithexternal GPS/magnetometerunits. Dedicatedbootloaderbuttonforeasyfirmwareflashing. Low-profiledesignfitsintoevenverycompactframes. Inputvoltage 7vto 42
...
