Gyro Unit Set For Kyosho Mini-Z RC Car Parts Description: Weight: 1g Wire Length: 80mm This Gyro Unit plugs right into the main board of your MR-03 & will help you keep your MR-03 under control. The Gyro Unit will automatic correct of steering & throttle. Basically it will keep the steering aimed to the global direction, so say your rear tires loose traction & the chassis come to an angle, this will counter steer for you faster than humanely possible. Very cool, & really impressive having the car stable like if it was following a rail on low traction surfaces (wood, tiles). Package Included:1 XGyro Unit Set ...

Description: Weight: 1g Wire Length: 60mm This Gyro Unit plugs right into the main board of your MINI-Z AWD Sports MA-020S/ Overland sports/ Mini-Z Racer sports 2 MR-03and will help you keep your vehicle under control. The Gyro Unit will automatic correct of steering & throttle. Basically it will keep the steering aimed to the global direction, so say your rear tires loose traction & the chassis come to an angle, this will counter steer for you faster than humanely possible. Very cool, & really impressive having the car stable like if it was following a rail on low traction surfaces (wood, tiles). Package Included:1 x Gyro Unit Set ...

Description: The USB (Universal Serial Bus) Adapter HS lets you connect a PC or Android phone (need OTG to USB (Universal Serial Bus) converter) to the I.C.S. plug on your MINI-Z, & means that you can adjust various setting parameters. It supports the latest EVO chassis (only PC software available) & all previous Mini-z chassis (both PC software & Android app available). It also could be used to upgrade transmitters like EX-6, EX-6R, EX-1, EX-2, EX-RR. For KO PROPO transmitter/ESC/SERVO settings, you could download software from:http://kopropo.com/america/support/ics-interactive-communication-system/ For Kyosho transmitter & Mini-z, , you could download software fromhttp://kyosho.com/mini-z-info/support/settings-&-firmwaresoftware/ Package Included:1 x Das Mikro I.C.S. USB (Universal Serial Bus) Adaptor HS1 x 3P servo cable (for transmitter upgrade)1 x 3P to 4P cable (for Mini-z ICS settings) ...

null Description: This RC receiver unit is KYOSHO ASF compatible. It offers full 4-channel support in ultra-light weight & micro size. It is designed for micro racing cars.
Features:1. KYOSHO 2.4 G Hz ASF compatible 2. High performance CPU enhance exactness control feeling 3. 4 channel support 4. Micro size (19mm x 12mm)5. Ideal for any micro RC racing chassis 6. Added failsafe function 7. Operating Voltage 3.7V
- 8.4V:8. Product Weight: 2g Compatible Transmitters:KO PROPO EX-1 ASFKO PROPO EX-6RKO PROPO EX-6KYOSHO KT-18KO PROPO EX-5UR ASFKO PROPO 901SM/902SM RF Module Package Included:1 x Receiver 2 x 1.5mm 3P JST plug with cable Bind & Failsafe: Power on your transmitter & receiver. Adjust transmitter each channel to the exact position you want to have in failsafe mode. Transmitter set to pair mode. Receiver led should be on. Long press the pair button. After around 2 seconds the LED will turn to fast flashing first then turn to on status again. Now the pairing is done & the failsafe data is saved. Power off the transmitter & receiver then power on again then the receiver will work. Wire Connection:

...

Das Mikro Micro Digital Servo Drive Board For Mini-Z MR03 AWD Servo Description: Digital servo drive board for Mini-Z MR03, AWD servo assembly. Very quick response speed. Maximum input 5.3V. It also could be used to transfer micro racing chassis to standalone receive. Like Mini-Z MR03/AWD, Mini-Z Lit, Dnano, Epoch 1/43, PNR2.5W, AMZ, AMR, ATM AMZ BZ & many aftermarket chassis Technical Data: Net Weight: 1g Operating Voltage: 3.6VS~5.3V
Size: 9*7*3mm Package Included:1 x Micro Digital Servo Drive Board
...

Description: Item Brand: Das Mikro Item Name:USB Programming Cable
Material:ABS & electronic components
Colour:

...

Das Mikro Programmable Sound Unit for Europe & US Trailer Truck Description: This sound unit is developed for electric powered RC trailer or truck. It could be used to 1:32, 1/24 & 1/18 RC vehicles, especially suitable for 1:24 ITALERI & Revell 1:24 series model RC conversion. rovide more than 30 different sound files for many Europe & US trailer & truck engines.

Features:- Sound quality 22 K Hz- Internal 1W amplifier at 8 Ohm speakers- Receiver signals are used for speed information, this allowsbrushlessor DC Motorusage- Fully assembled in SMD technology (no heavy, vibration sensitive components)- All wires included- Very littledimensionandweight Technical Data: Brand: Dasmikro Item: Programmable Sound Unit Dimension: 11 x 23, 5 x 3, 2mm (min.11x 16x 3, 2mm) Voltage: 3V to 5V (supplied by the receiver) Note the maximum supply voltage of 5V! Current: app. 10m A without sound, app. 250m A at max. volume Speaker: 8-32 Ohm Output power: 1W at 8-Ohm at 5V; 0, 6W at 8-Ohm at 3 V Proportional inputs: 1ms to 2ms Sound quality: up to 22 k Hz Sound selection play by a 3 position switch (toggle switch) This control mode need a toggle switch with neutral position (recommended), or a common proportional channel. Selecting a sound or function: The desired sound (e.g sound 3 or function) is selected by pushing the switch/stick 3 times from its neutral position to high position (1.8ms). The selected sound/fuction is triggered/played by pushing the switch/stick to low position (1.2ms). The last selected sound/func

...

Programmable Sound Unit for Orlandoo F150 OH35P01 KIT Micro RC Crawlers Description: This soundunit is developed specially for electric powered RC. It could be used to 1:35, 1/24 & 1/18 RC crawlers. Especially suitable for Orlandoo F150 OH35P01 KIT Assemble Climbing RC Car Parts Version
Features: Plug & Play Soundquality 22 K Hz Internal 1W amplifier at 8 Ohm speakers All connections done by plugs, no solderwork necessary Receiver signals are used for speed information, this allows brushless or DC Motor usage Fully assembeled in SMD technology (no heavy, vibration sensitive components) All wires included Very little

Dimensions & weight Technical Datas: Dimensions: 11 x 23, 5 x 3, 2mm (min.11x 16x 3, 2mm) Voltage: 3V to 5V (supplied by the receiver) Note the maximum supply voltage of 5V! Current: app. 10m A without sound, app. 250m A at max. volume Speaker: 8-32 Ohm Output power: 1W at 8-Ohm at 5V; 0, 6W at 8-Ohm at 3 V Proportional inputs: Positive Impuls 0, 8ms bis 2, 0ms Soundquality: up to 22, 05 k Hz Teaching the sound unit for throttle idle/accelerate point:1. Power on transmitter & receiver. LED blinks fast
- normal mode. Bring throttle stick to idle. Motor must not move.2. Bridge study switch for about 0.5 seconds until beep
- LED cont. on. At this moment the idle position of the throttle stick is stored.3. Move throttle stick to your desired acceleration point (throttle stick position where idle dead band stops & engine running sound starts) & wait for a beep. Now the dead (neutral) band of th




...

Programming Cable For RC Tractor Sound Unit Programming New Sounds Choosing Different Sounds/ Light Description: This programming cable is developed specially for RC Tractor Sound Unit. With this programming cable you could switch 4 different tractor sounds provided, & you can reveal so much new function on Sound Unit, not only program new sounds, but you can also use channel 3 to choose from 16 different sound or & light control functions. For TBS Micro Sound Unit manual, Programming Software, Programming Software Manual, USB Driver, Sound library, Please click HERE. Package Included:1 X Programming Cable ...

Programming Cable for TBS Micro Sound Unit Description: This programming cable is developed specially for TBSMicro Sound Unit. Pleae Click 1, 2 for:TBS Micro Sound Unit manual Programming Software Programming Software Manual USB Driver Sound library Package Included: 1 X Programming Cable ...
