Specification: Brand Name: LDARCModel: ET85 D Item Name: 87.6mm Wheelbase F4 4S 2 Inch FPV Racing Drone Version: PNP (without Receiver) Drone Weight: 122g ET85D 87.6mm Frame Kit Wheelbase: 87.6mm
Material: Carbon Fiber Upper Plate Thickness: 1mm Bottom Plate Thickness: 2mm Camera Angle: 15-45 Degree Kit Weight: 24g F411E12A F4 Flight Controller AIO 12A ESCBrand Name: LDRACModel: F411E12 A Item Name: F4 Flight Controller MCU: STM32F411MPU: MPU6000 Firmware Target: MATEKF411OSD: AT7456E, Support Betaflight OSDOnboard Current Senstor (Current Scale value 210) Support DSM2/X, SBUS, IBUS, Crossfire, F. Port Receiver Input Voltage: 2-4S Lipo ESC Max Current 12A Each Way B Lheli_S 4in 1 ESC, Target: G_H_30XT1105 4250 3-4S Brushless Motor Brand Name: LDARCModel: XT1105 Item Name: 1105 4250KV Motor Input Voltage: 3-4S Lipo Shaft Diameter: 1.5mm Mounting Hole: 9x 9mm, M2 Weight: 6.1g 2045 2x 4.5 2 Inch 4-Blade Propeller Brand Name: LDARCItem Name: 2045 2x 4.5 2 Inch 4-Blade Propeller Quantity: 10 CW10 CCW5.8G 48CH 25/100/200m W FPV Transmitter Power: 0/25/100/200m W Working Voltage: 5V, Support IRC-Tramp Camera 5V Power Output CLC filter Antenna Use IPEX Socket FPV Camera (NOT Included)NO Camera, support 19mm / 20mm Width FPV Camera Receiver (NOT Included)NO Receiver Lipo Battery (NOT Included) Recommend LDARC 4S 14.8V 430m Ah Lipo Battery XT30 Plug

Features:- 4S HD Digital Whoop- Compatible with Caddx Vista Module- Light Weight, less than 250g Package Included:1x ET85D FPV Drone (NOT Include DJI Air Unit, Receiver, Camera)1


...

Description: Brand:LDARC/ KINGKONGCenter Hole Diameter: 25*25mm Mounting

Size: 20*20mm Firmware: MATEKF411

...

LDARC F411E12A F4 Flight Controller AIO OSD BECBuilt-in 12A BL_S 2-4S 4in 1 ESCNotice: ONLY Includeflight controller.DO NOT included VTX Module. Cilick here to buy VTX Moduletogether. Specification: Brand Name: LDARCModel:F411E12 A Item Name: F4 OSD Flight Controller AIO BEC Current Sensor 12A 4in 1 ESCMCU: STM32F411 Gyroscope: MPU6000OSD: AT7456EBEC: 5V@1.5A, max. 3 A Firmware: MATEKF411 Current Scale Value: 210ESC: 4in 1 12A BLheli_S C-H-30ESC Max Current 12A Each Way Input Voltage: 2-4SLED Pad: Yes Buzzer Pad: Yes Application: compatible with LDARC ET75 / ET85/ AK103/ AK123, Beta 85X, Mobula 7 etc. whoop fpv racing drone. Package Included:1x LDARCF411E12A F4 FC AIO 12A ESC1x Cable 8x Anti-Vibration Standoffs 3x Screws ...

LDARC Kingkong KK 220 F4 OSD 20A BL_S FPV Racing Drone w/ 25/100/200m W VTX Runcam Swift Mini PNPSpecification: Brand Name: LDARCModel: KK 220 Item Name: 220mm F4 OSD FPV Racing Drone Version: PNP (Without Receiver & Battery) Wheelbase: 220mm
Material: Carbon Fiber 7075 Aluminum Alloy Input Voltage: 3-4 S Recommend Battery: 4S 1300m Ah above 25C Lipo Weight: 244.4g (Without Receiver & Battery)220mm Frame Kit Wheelbase: 220mm
Material: Carbon Fiber 7075 Aluminum Alloy Arm Thickness: 5mm Weight: 93.1KK20 3 Layer Flytower F4 FC20A ESCVTXTower Monting Hole: 20x 20mm (M2) Tower

Height: 21mm Tower Weight: 15.9g LDARC Omnibus F4 FCFirmware: Omnibus F4SD- Built-in Betaflight OSDOutput Voltage for Camera: 5V
Size: 25x 25mm Mounting Hole: 20x 20mm Weight: 4g (Support DSMX, SBUS & PPM Receiver 20A 4 in 1 ESCCon. Current: 20 A Peak Current: 25A (5s) Firmware: BLHeli_SInput Voltage: 2-4S
Size: 29x 31mm Mounting Hole: 20x 20mm Net Weight: 5.3g Support Oneshot, Multishot, DShot 150/300 & DShot 6005.8G 48CH 0/25/100/200m W VTX (Top Level) Channel: 25CHPower:0/25/100/200m W (Switchable) Output Voltage for Camera: 5V
Size: 25x 25mm Mounting Hole: 20x 20mm Weight: 2g Blue Lightpoints at the CH indicator (CH1-CH8, flashes 1-8 times) Green Lightpoints at the Band Indicator ( Band A- Band F, flashes 1-6 times) Red Lightpoints at the Power Indicator (25-100m W, flashed 1-3 times)XT1806 2500KV Motor Brand Name: LDARCModel: XT1806 Item Name: 1806 2500KV 3-4S Brushless Motor Version: CW / CCW (Optional)KV: 2500KVInput Voltage: 3-4S Lipo Max.






...

LDARC Kingkong KK 5GT 213mm F4 OSD FPV Racing Drone w/ BL_S 48CH 25/200/600m W VTX Runcam Swift Mini Specification: Brand Name: LDARCModel: KK 5GTItem Name: 213mm F4 OSD FPV Racing Drone Version: PNP (Without Receiver & Battery) Wheelbase: 213mm
Material: Carbon Fiber 7075 Aluminum Alloy Input Voltage: 3-4 S Recommend Battery: 4S 1300-1800m Ah above 25C Lipo Weight: 336.7g (Without Receiver & Battery)213mm Frame Kit Wheelbase: 213mm
Material: Carbon Fiber 7075 Aluminum Alloy Arm Thickness: 5mm Weight: 102.5g KK Super Flytower FC AIOVTXTower Monting Hole: 30.5x 30.5mm Tower

Height: 16.5mm (Include heat sink ) Tower Weight: 28.9g F4 Flight Controller Integrated with VTX Module: Chip: STM32f 405 MCUGyroscope: MPU6000 Firmware: OMNIBUSF4SDOSD: Betaflight OSD With 5V @ 3A (VTX & FC have been used. Suggest less than 6 LED ) ( If use more than 6 LED, please use BEC Module ) Support PPM Recceiver/SBUS/DSMX Receiver (PPM Receiver need solder the pad) Channel: 48CHPower: Off/25/200/600m W (TX control through the Furious FPV / Tramp peropheral protocol ) Camera Voltage: 5 V Weight: 11.3g
Size: 36x 36mm (30.5x 30.5mm Mounting Hole)KK Super Flytower 40A BLheli_S 4 in 1 ESCWorking Voltage: 2-4S Lipo Con. Current: 40 A Burst Current: 45A (5S) Firmware: BLheli_S/ Dshot 150/DShot 300/DShot 600 16.6 (G_H_30)
Size:39x 41mm (with pad ) Moutning Hole: 30.5x 30.5mm Weight: 12.5g Support BLHeli Suite setting-Integrated PDB, -Integrated Battery Monitoring- Integrated FC Power XT2306 2500KV Motor Model: XT2306KV: 2500KVLipo Battery: Support 3-4SS





...

LDARC Kingkong KK Super Flytower Part MMCX to SMA Female Antenna Extension Cable Specification: Brand Name: LDARCItem Name:MMCX to SMA Female Antenna Extension Cable Connector: MMCX to SMA Female Length: 105mm Application: Original Part for LDARC KK Super Flytower Package Included:1x LDARCAntenna Extension Cable ...

Kingkong 90GT Spare Part Micro F3 Mini 6 Dof Flight Control Board Hardware Connection Diagram Firmware Update Default setting of Receiver is 5th Channel ARM; 6th Channel Mode switching. Specification: Brand Name: Kingkong Item Name: Micro F3 6 Dof Flight Control Board Input Voltage: 2-4S Lipo
Size: 35.1*19.6*6.52mm Weight: 3.05g Usage: Original Flight Control Spare Part for Kingkong 90GT Drone Package Included:1x Kingkong Micro F3 Flight Control
...

LDARC Kingkong XT2306 1700KV 4-6S Brushless Motor with Motor Mounting Base for KK 5GT RC Drone Specification: Brand Name: LDARCModel: XT2306 Item Name: 2306 1700KV 4-6S Brushless Motor Version: CW / CCW (Optional)KV: 1700KVInput Voltage: 4-6S Lipo Shaft Diameter: M5 Motor

Width: 28mm Motor

Height: 31.7mm Weight: 34.1g Recommend Propeller: 7 Inch (4S) / 5-6 Inch (5S)5 Inch (6S) Application: Compatible with for LDARC KK 5GT FPV Drone Package Included:1x XT2306 1700KV Motor (CW / CCW )1x Motor Mounting Base (Red)1x bag of Screws



...

LDARC Kingkong XT2306 2500KV 3-4S Brushless Motor w/ Mounting Base for KK 5GT FPV Racing Drone Specification: Brand Name: LDARCModel: XT2306 Item Name: 2306 2500KV 3-4S Brushless Motor Version: CW Rotation with Black Nut CCW Rotation with Sliver Nut (Optional)KV: 2500KVInput Voltage: 3-4S Lipo Shaft Diameter: M5 Motor

Width: 28mm Motor

Height: 31.7mm Weight: 34.1g Recommend Propeller: 5150 Application: original part for LDARC KK 5GT FPV Drone Package Included:1x XT2306 2500KV Motor (CW Or CCW )1x Motor Mounting Base 1x bag of Screws



...

LDARC KK 220 FPV Drone Part IPEX to SMA Female Antenna Extend Cable Specification: Item name: Adapter Extend Cable Connector: IPEX to SMA Female Application: Original part for LDARC KK 220 Drone Package included:1 x IPEX to SMA Female Extend Cable ...
