Specification: Quantity: 1pcs
Colour: Grey + Green
Height: 62cm / 24.41 Item Sub-Type: Towing Type: Caravan

...

Only US$21.99, buy best matcha mint green mechanical keyboard xda profile keycap set 127-key pbt sublimation customed keycaps suitable for 61 68 84 87 96 108 980 mechanical keyboards sale online store at wholesale price. ...

Specification: Brand Name: Mate 2GO
Size: 98mm X 98mm X 35mm Input voltage: 5 (V) Type A: Air outlet type base type Type
...

Matek 4S Lipo to 12V Linear Voltage Regulator Regulate Module For FPV Camera Multicopter Description: Brand Name: Matek Item Name: Linear Voltage Regulator Input Voltage:13~17V, 4S Li Po Output Voltage: 12V, accuracy 2.5% Output Current: Continuous 300m A
Size: 25*10*3mm Weight: 1g
Features: Suitable for FPV Camera Compared with BEC12V, linear voltage regulator with low-ripple, doest interfere the image signal Temp. 25℃, 16V input, 12V output 300m A, 5min, the highest measured temperature is 58℃ Can be connected with extra only one 12V 1.5W LED light. If the 3S & 4S mixed, it support 3S battery too. Output voltage=3S voltage-1V, eg. the battery voltage is 12V, actual output is 11V, & the camera can work normally. Package Included:1 x Module

...

Matek 5.8G 40CH 25/200/500m W switchable Video Transmitter VTX-HV with 5V/1A BEC Output Specifications Features (user manual): Input voltage: 7~27V (2~6S Li Po)40 standard channels, A/B/E/F/R Band Output Power: 25, 200, 500m W switchable BEC Output: 5V/1A for Camera or FCTraditional button+LED control of frequency & power BFCMS (BFOSD LUA Script) control via FC UART _TXFirmware upgradeable Power Consumption: 3.1W Max. @ 500m W Video Input Impedance: 75 Ohm Audio Subcarrier Frequency: 6.5 MHz RF Connector: U.FL (IPEX) Video Format: NTSC/PALWeight: 6g (Tx only, w/o SMA cable)
Size: 36*22*6.5mm w/30.5mm mounting Package included:1x 5.8G Video transmitter (MMCX)1x PVC Heat-shrink tube 1x MMCXto SMA Female, RG178 cable 9cm
...

Matek Beta Flight F405-CTR Flight Controller Built-in PDB + Matek 5.8G Video Transmitter VTX-HVSpecification: Matek F405-CTR (User manual): Brand name: Matek Systems Item name: Beta Flight F405-CTR
Size: 36x 46mm PCB with 30.5mm mounting holes Weight: 10g FC:MCU: 168 M Hz STM32F405IMU: MPU6000 accelerometer/gyro (SPI) Baro: BMP280 (I2C)OSD: Beta Flight OSD w/ AT7456E chip Blackbox: Micro SD card slot (SD/SDHC)VCP, UART1, UART2, UART3, UART4, UART5 Built in inverter for SBUS input (UART2-RX)PPM/UART Shared: UART2-RXSoft Serial on TX2, S5 or S6 optional Camera control on S6 or DAC optional Smartaudio Tramp VTX protocol supported WS2812 Led Strip: Yes Beeper: Yes RSSI: Yes PDB: Input: 6~30V (3~6S Li Po) w/TVS protection PDB: 4x 30A (Max.4x 46A), 6 layers*2oz copper PCBBEC: 5V 2A cont. (Max.3A)LDO 3.3V: Max.300m A for Spektrum RXCurrent Sensor 184A (Scale 179) Battery Voltage Sensor: 1:10 (Scale 110) Matek 5.8G VTX-HV MMCX Ver. (user manual): Input voltage: 7~27V (2~6S Li Po)40 standard channels, A/B/E/F/R Band Output Power: 25, 200, 500m W switchable BEC Output: 5V/1A for Camera or FCTraditional button+LED control of frequency & power BFCMS control via FC UART _TXFirmware upgradeable Power Consumption: 3.1W Max. @ 500m W Video Input Impedance: 75 Ohm Audio Subcarrier Frequency: 6.5 MHz RF Connector: U.FL (IPEX) Video Format: NTSC/PALWeight: 6g (Tx only, w/o SMA cable)
Size: 36*22*6.5mm w/30.5mm mounting Package included:1x Matek Systems Beta Flight F405-CTR1x Rubycon ZLH 35V/470u F (Low ESR)6x silicon grommets M4 to M31x FR

...

Only US$11.99, buy best matek crsf-pwm-v 10 crsf to pwm converter w/ variometer 10ch pwm output for tbs crsf protocol 2.4ghz 915mhz 868mhz 433mhz receiver sale online store at wholesale price. ...

Real Test of output voltage Input voltage output Electric current Effectiveness Curve Description: Input voltage range: 3~4.2V DCOutput: 5V 2 A Standby current: 5m A Pins distance: 2.54mm Size Weight: 27x 15x 3mm, 2g

Features:-VB2A5 is a compact, high-efficiency, synchronous step-up converter for asingle-cell Li-ion/polymer battery. It can boost the voltage to 5V, allowing youto run a receiver on a single cell lipo.-Use for 1cell Li-ion or Li Po.-Synchronous step-up converter.-Guaranteed 2A Output Current at VOUT = 5V from 3.3V Input-Reverse input polarity protection.-Over-temperature protection. Package Include:1x Voltage Booster

...

Matek Systems F405-STD Beta Flight STM32F405 Flight Controller Built-in Inverter for SBUS Input Specification (user manual): Brand: Matek Systems Item name: Flight Control Board
Size: 36x 36mm Mounting hole: 30.5mm Weight: 7g MCU: 168 M Hz STM32F405RGT6IMU: 32K ICM20602 gyro/accelerometer (SPI) Baro: BMP280 (I2C)OSD: Beta Flight OSD w/ AT7456E chip Blackbox: Micro SD card slot (SD/SDHC)VCP, UART1, UART2, UART3, UART4, UART5 Built in inverter for SBUS input (UART2-RX)PPM/UART Shared: UART2-RXSoft Serial on TX2, S5 or S6 optional Camera control on S6 or DAC optional Smartaudio Tramp VTX protocol supported Battery Voltage Sensor: 1:10 Current Sensor: No (FCHUB-6S, FCHUB-VTX, FCHUB-W option)BEC 5V: No (FCHUB-6S, FCHUB-VTX, FCHUB-W option)LDO 3.3V: Max.300m AI2C1 SDASCL: Yes WS2812 Led Strip: Yes Beeper: Yes RSSI: Yes
Features:3x LEDs for FC STATUS (Blue, Red) & 3.3V indicator (Red)6x PWM / DShot outputs without conflict 2x 2812LED outputs option 5x UARTs 1x Group of 5V/G/S1/S2/S3/S4 pads for 4in 1 ESC Signal/GND4x pairs of corner pads for ESC Signal/GND connections (DSHOT compatible)1x pair I2C1 pads 1x Side-press button for BOOT (DFU) mode 1x 16pin bottom mounted FFC Slot for FCHUB-6S, FCHUB-VTX or FCHUB-W connection Package included:1x flight control board 2x 0.5mm*16 Pin 5cm Flexible Flat Cable 4x M3 Anti-vibration Standoffs

...

Matek F405-STDBeta Flight STM32F405 Flight Controller + Matek FCHUB-6S Hub Power Distribution Board Specification: Matek F405-STD (user manual): Brand: Matek Systems Item name: Flight Control Board
Size: 36x 36mm Mounting hole: 30.5mm Weight: 7g MCU: 168 M Hz STM32F405RGT6IMU: 32K ICM20602 gyro/accelerometer (SPI) Baro: BMP280 (I2C)OSD: Beta Flight OSD w/ AT7456E chip Blackbox: Micro SD card slot (SD/SDHC)VCP, UART1, UART2, UART3, UART4, UART5 Built in inverter for SBUS input (UART2-RX)PPM/UART Shared: UART2-RXSoft Serial on TX2, S5 or S6 optional Camera control on S6 or DAC optional Smartaudio Tramp VTX protocol supported Battery Voltage Sensor: 1:10 Current Sensor: No (FCHUB-6S, FCHUB-VTX, FCHUB-W option)BEC 5V: No (FCHUB-6S, FCHUB-VTX, FCHUB-W option)LDO 3.3V: Max.300m AI2C1 SDASCL: Yes WS2812 Led Strip: Yes Beeper: Yes RSSI: Yes Matek FCHUB-6S (user manual): Brand Name: Matek Model:FCHUB-6 S Item Name: Power Distribution Board Built-in Current Sensor
Size: 36x 36mm 30.5x 30.5mm Hole Mounting, M3 Weight: 8.5g BEC Output: 5V10V5V BEC Output:- Designed for RC Receivers, Flight Controllers, OSD & Servos.- DC/DC synchrous buck regulator- Voltage: 5.0V (4.9-5.1)DC
- Current: 1.5A (Max. 2.0A 10S/minute)- Short-circuit tolerant (2 Seconds/minuate)10V BEC Output:-Designed for VTX or FPV Camera- Voltage: 10.0V (9.8-10.2) DC
- Current: 1.5A (Max. 2.0A 10S/minute)- Short-circuit tolerant (2 Seconds/minuate)- 10V can be used to power cameras labeled as 12V.- The 3S Lipo input voltage should be 11V plus. Curr



...
