Specification: Brand Name: Mate 2GO
Size: 98mm X 98mm X 35mm Input voltage: 5 (V) Type A: Air outlet type base type Type
...

Matek 4S Lipo to 12V Linear Voltage Regulator Regulate Module For FPV Camera Multicopter Description: Brand Name: Matek Item Name: Linear Voltage Regulator Input Voltage:13~17V, 4S Li Po Output Voltage: 12V, accuracy 2.5% Output Current: Continuous 300m A
Size: 25*10*3mm Weight: 1g
Features: Suitable for FPV Camera Compared with BEC12V, linear voltage regulator with low-ripple, doest interfere the image signal Temp. 25℃, 16V input, 12V output 300m A, 5min, the highest measured temperature is 58℃ Can be connected with extra only one 12V 1.5W LED light. If the 3S & 4S mixed, it support 3S battery too. Output voltage=3S voltage-1V, eg. the battery voltage is 12V, actual output is 11V, & the camera can work normally. Package Included:1 x Module

...

Matek 5.8G 40CH 25/200/500m W switchable Video Transmitter VTX-HV with 5V/1A BEC Output Specifications Features (user manual): Input voltage: 7~27V (2~6S Li Po)40 standard channels, A/B/E/F/R Band Output Power: 25, 200, 500m W switchable BEC Output: 5V/1A for Camera or FCTraditional button+LED control of frequency & power BFCMS (BFOSD LUA Script) control via FC UART _TXFirmware upgradeable Power Consumption: 3.1W Max. @ 500m W Video Input Impedance: 75 Ohm Audio Subcarrier Frequency: 6.5 MHz RF Connector: U.FL (IPEX) Video Format: NTSC/PALWeight: 6g (Tx only, w/o SMA cable)
Size: 36*22*6.5mm w/30.5mm mounting Package included:1x 5.8G Video transmitter (MMCX)1x PVC Heat-shrink tube 1x MMCXto SMA Female, RG178 cable 9cm
...

MATEK Analog Pixel OSD Module 9-30V Support 8V Boost to 12V Voltage Power Regulater for FPV VTX Camera Flight Controller Description Brand Name: Matek Model: OSD Module Vbat/DC IN: 9-30 V On board regulator: 2A, 8v rise to 12v Note: Only Artificial Horizontal is graphical in INAV firmware, no graphical elements in BF firmware for now. Package Included 1 x OSD Module ...

Matek Beta Flight F405-CTR Flight Controller Built-in PDB + Matek 5.8G Video Transmitter VTX-HVSpecification: Matek F405-CTR (User manual): Brand name: Matek Systems Item name: Beta Flight F405-CTR
Size: 36x 46mm PCB with 30.5mm mounting holes Weight: 10g FC:MCU: 168 M Hz STM32F405IMU: MPU6000 accelerometer/gyro (SPI) Baro: BMP280 (I2C)OSD: Beta Flight OSD w/ AT7456E chip Blackbox: Micro SD card slot (SD/SDHC)VCP, UART1, UART2, UART3, UART4, UART5 Built in inverter for SBUS input (UART2-RX)PPM/UART Shared: UART2-RXSoft Serial on TX2, S5 or S6 optional Camera control on S6 or DAC optional Smartaudio Tramp VTX protocol supported WS2812 Led Strip: Yes Beeper: Yes RSSI: Yes PDB: Input: 6~30V (3~6S Li Po) w/TVS protection PDB: 4x 30A (Max.4x 46A), 6 layers*2oz copper PCBBEC: 5V 2A cont. (Max.3A)LDO 3.3V: Max.300m A for Spektrum RXCurrent Sensor 184A (Scale 179) Battery Voltage Sensor: 1:10 (Scale 110) Matek 5.8G VTX-HV MMCX Ver. (user manual): Input voltage: 7~27V (2~6S Li Po)40 standard channels, A/B/E/F/R Band Output Power: 25, 200, 500m W switchable BEC Output: 5V/1A for Camera or FCTraditional button+LED control of frequency & power BFCMS control via FC UART _TXFirmware upgradeable Power Consumption: 3.1W Max. @ 500m W Video Input Impedance: 75 Ohm Audio Subcarrier Frequency: 6.5 MHz RF Connector: U.FL (IPEX) Video Format: NTSC/PALWeight: 6g (Tx only, w/o SMA cable)
Size: 36*22*6.5mm w/30.5mm mounting Package included:1x Matek Systems Beta Flight F405-CTR1x Rubycon ZLH 35V/470u F (Low ESR)6x silicon grommets M4 to M31x FR

...

Real Test of output voltage Input voltage output Electric current Effectiveness Curve Description: Input voltage range: 3~4.2V DCOutput: 5V 2 A Standby current: 5m A Pins distance: 2.54mm Size Weight: 27x 15x 3mm, 2g

Features:-VB2A5 is a compact, high-efficiency, synchronous step-up converter for asingle-cell Li-ion/polymer battery. It can boost the voltage to 5V, allowing youto run a receiver on a single cell lipo.-Use for 1cell Li-ion or Li Po.-Synchronous step-up converter.-Guaranteed 2A Output Current at VOUT = 5V from 3.3V Input-Reverse input polarity protection.-Over-temperature protection. Package Include:1x Voltage Booster

...

Matek Systems F405-STD Beta Flight STM32F405 Flight Controller Built-in Inverter for SBUS Input Specification (user manual): Brand: Matek Systems Item name: Flight Control Board
Size: 36x 36mm Mounting hole: 30.5mm Weight: 7g MCU: 168 M Hz STM32F405RGT6IMU: 32K ICM20602 gyro/accelerometer (SPI) Baro: BMP280 (I2C)OSD: Beta Flight OSD w/ AT7456E chip Blackbox: Micro SD card slot (SD/SDHC)VCP, UART1, UART2, UART3, UART4, UART5 Built in inverter for SBUS input (UART2-RX)PPM/UART Shared: UART2-RXSoft Serial on TX2, S5 or S6 optional Camera control on S6 or DAC optional Smartaudio Tramp VTX protocol supported Battery Voltage Sensor: 1:10 Current Sensor: No (FCHUB-6S, FCHUB-VTX, FCHUB-W option)BEC 5V: No (FCHUB-6S, FCHUB-VTX, FCHUB-W option)LDO 3.3V: Max.300m AI2C1 SDASCL: Yes WS2812 Led Strip: Yes Beeper: Yes RSSI: Yes
Features:3x LEDs for FC STATUS (Blue, Red) & 3.3V indicator (Red)6x PWM / DShot outputs without conflict 2x 2812LED outputs option 5x UARTs 1x Group of 5V/G/S1/S2/S3/S4 pads for 4in 1 ESC Signal/GND4x pairs of corner pads for ESC Signal/GND connections (DSHOT compatible)1x pair I2C1 pads 1x Side-press button for BOOT (DFU) mode 1x 16pin bottom mounted FFC Slot for FCHUB-6S, FCHUB-VTX or FCHUB-W connection Package included:1x flight control board 2x 0.5mm*16 Pin 5cm Flexible Flat Cable 4x M3 Anti-vibration Standoffs

...

Matek F405-STDBeta Flight STM32F405 Flight Controller + Matek FCHUB-6S Hub Power Distribution Board Specification: Matek F405-STD (user manual): Brand: Matek Systems Item name: Flight Control Board
Size: 36x 36mm Mounting hole: 30.5mm Weight: 7g MCU: 168 M Hz STM32F405RGT6IMU: 32K ICM20602 gyro/accelerometer (SPI) Baro: BMP280 (I2C)OSD: Beta Flight OSD w/ AT7456E chip Blackbox: Micro SD card slot (SD/SDHC)VCP, UART1, UART2, UART3, UART4, UART5 Built in inverter for SBUS input (UART2-RX)PPM/UART Shared: UART2-RXSoft Serial on TX2, S5 or S6 optional Camera control on S6 or DAC optional Smartaudio Tramp VTX protocol supported Battery Voltage Sensor: 1:10 Current Sensor: No (FCHUB-6S, FCHUB-VTX, FCHUB-W option)BEC 5V: No (FCHUB-6S, FCHUB-VTX, FCHUB-W option)LDO 3.3V: Max.300m AI2C1 SDASCL: Yes WS2812 Led Strip: Yes Beeper: Yes RSSI: Yes Matek FCHUB-6S (user manual): Brand Name: Matek Model:FCHUB-6 S Item Name: Power Distribution Board Built-in Current Sensor
Size: 36x 36mm 30.5x 30.5mm Hole Mounting, M3 Weight: 8.5g BEC Output: 5V10V5V BEC Output:- Designed for RC Receivers, Flight Controllers, OSD & Servos.- DC/DC synchrous buck regulator- Voltage: 5.0V (4.9-5.1)DC
- Current: 1.5A (Max. 2.0A 10S/minute)- Short-circuit tolerant (2 Seconds/minuate)10V BEC Output:-Designed for VTX or FPV Camera- Voltage: 10.0V (9.8-10.2) DC
- Current: 1.5A (Max. 2.0A 10S/minute)- Short-circuit tolerant (2 Seconds/minuate)- 10V can be used to power cameras labeled as 12V.- The 3S Lipo input voltage should be 11V plus. Curr



...

Matek FCHUB-6S Hub Power Distribution Board 5V10V BEC Built-in 184A Current Sensor Describtion:-This PDB distribution power from from a 3-6S Lipo pack to 4 ESCs, as well as providing regulatedfiltered DC 5VDC 10V outputs for powering Cameras, RC receivers, Flight Controllers, Video Transmitters, LEDs, etc.- It also has buit-in 184A current sensor & offers a FFC socket to connect the Matek flight controller conviently. Specification: Brand Name: Matek Model:FCHUB-6 S Item Name: Power Distribution Board Built-in Current Sensor
Size: 36x 36mm 30.5x 30.5mm Hole Mounting, M3 Weight: 8.5g BEC Output: 5V10V5V BEC Output:- Designed for RC Receivers, Flight Controllers, OSD & Servos.- DC/DC synchrous buck regulator- Voltage: 5.0V (4.9-5.1)DC
- Current: 1.5A (Max. 2.0A 10S/minute)- Short-circuit tolerant (2 Seconds/minuate)10V BEC Output:-Designed for VTX or FPV Camera- Voltage: 10.0V (9.8-10.2) DC
- Current: 1.5A (Max. 2.0A 10S/minute)- Short-circuit tolerant (2 Seconds/minuate)- 10V can be used to power cameras labeled as 12V.- The 3S Lipo input voltage should be 11V plus. Current Sensor Module
- Max. Range: 184A- 3.3V ADC- Scale the output voltage to milliamps (1/10th m W/A): 179

Features:- Total 4 pairs ESC solder tabs are fix for X Type frame- Max. 27V input w/ TVS protection- Built-in current sensor 184A- PDB: 4*30A (4*46A, 5 seconds), 4 layers*2oz copper PCB-BEC 5V@1.5A (Max. 2A) w/ 100uf panasonic POSCAP filter
- BEC 10V@1.5A (Max. 2A) w/ 47uf TDK MLCC filter- 5V10V out






...

Matek FCHUB-W Fixed Wings PDB 3-6S Built-in 4 BEC & 104A Current Sensor for RC FPV Racing Drone Specification (user manual): Input voltage range: 9~30V (3~6S Li Po) w/TVS protection Current Senor: 104A, 3.3V ADC, Scale 317 Mounting: 30.5 x 30.5mm, Φ3mm Dimensions: 52 x 36 x 6 mm Weight: 13g 2x ESC power pads 4x BEC on board 3x LED indicators for 5V, 10V & Vx Soldering Holes & Pads:+ & –: Bettery & ESC power pads Curr: Current sensor output Vbat: Bettery voltage G: Ground 3V3: LDO 3.3V5V: BEC 5V10V: BEC 10 V Vx: BEC 5V/6V/7.2V ADJFFC connection: Compatible with MATEKSYS FC F405-STD, F722-STD, F405-OSDMT1: Motor 1 of INAV Flying Wing & Airplane MT2: Motor 2 of INAV Flying Wing & Airplane SV3~SV6: Servo 3~6 of INAV Flying Wing & Airplane VTX: Video Transmitter signal TX5 & RX5: UART5 of F405-STD/F722-STD/F405-OSDBEC 5V output: Designed for Flight controller, Receiver, OSD, Camera, Buzzer, 2812 LED_ Strip, GPS module DC/DC synchronous buck regulator Voltage: 5.0 +/- 0.1VDCContinuous current: 2 Amps, Max.3 A Output Ripple: 20m V (VIn=24V, VOut=5V@2A load) Short-circuit tolerant (2 seconds)BEC 10V output: Designed for Video Transmitter, Gimble DC/DC synchronous buck regulator Voltage: 10.0 +/- 0.2VDC (Input voltage >11V) Continuous current: 2 Amps, Max.3 A Output Ripple: 20m V (VIn=24V, VOut=10V@2A load) Short-circuit tolerant (2 seconds)BEC Vx output: Designed for Servos DC/DC synchronous buck regulator Voltage adjustable, 5V Default, 6V or 7.2V via jumper Continuous current: 5 Amps, Max.5.5 A Output Ripple: 50m V (VIn=24V, V ...
